For more detail photos and video about Supro -Nicolas modular trailer, please check the link of  "Performance Case of Nicolas Modular Trailer".

Supro Modular Trailer- Nicolas Hydraulic modular trailer

1. Supro- Nicolas modular trailer could combine with Nicolas MDED, Nicolas MDE. Supro trailer is the first manufacturer of hydraulic modular trailer in China. And we have been studied the hydraulic modular trailer for over 20 years. So we are too mature on this technology!


2. Supro produced the first set of Hydraulic modular trailer in China that is to combine with the Nicolas hydraulic modular trailer. And we are the source of the Chinese hydraulic modular trailer technology.


3. Supro Trailer produce " Self propelled modular trailer" to combine with Nicolas SPMT.

nicolas self propelled modular trailer


4. For the Supro- Nicolas modular trailer. We have two strutures, one is 2990mm width, and another one is 3400mm width. 3400mm width modular trailer has a bigger loading capacity than 2990mm width modular trailer.


5. The Min.height of the Supro Nicolas modular trailer could be 660mm.

Nicolas Modular Trailer

Perfection design of the Supro-Nicolas modular trailer

1. Supro Trailer enforce the strength of the Nicolas modular trailer suspension. We change the Nicolas welding technology to be foundry technology! So it would happen breakage situation of the suspension.


2. We make the height of the beam( thickness) be more bigger to improve the loading capacity of the modular trailer platform.

Nicolas hydraulic modular trailer


3. We make the Nicolas modular trailer connection pins from 3pcs pins to be 4pcs pins. So the trailer has a better combination strength between each unit! And also it could load more heavier "Drop deck bed".

Nicolas MDED modular trailer

Supro Hydraulic Modular Trailer

1. Supro Hydraulic modular trailer could combine with Goldhofer modular trailerNicolas modular trailer, Scheuerle modular trailer and Cometto modular trailer.

Supro Hydraulic modular Trailer- Combine Goldhofer trailer

China hydraulic modular trailer


2. And also, Supro Trailer has own design on hydraulic modular trailer- "Supro Modular trailer".

The loading capacity of Supro modular trailer could reach 50 tons per axle! Please visit the product detail of the Supro modular trailer.

Nicolas multi axle trailer


3. Supro Trailer has a very prefessional technician team on Hydraulic modular trailer. Supro Modular Trailer already get though the CE certification, and exported to France market! "Supro CE modular trailer".

Nicolas modular trailer


4. Supro Trailer produce high standard hydraulic modular trailer for China rockets transport. And we design the modular trailer against on the rocket special transport demands.

Nicolas hydraulic modular trailer

Toolings for Hydraulic modular trailer

1. For heavy cargo such as Transformer, we could use "Girder Bridge" to transport the cargo!

Girder bridge trailer

2. Spacer for Hydraulic modular trailer

The Spacer combine with Hydraulic modular trailer to make the cargo platform be more longer. And the lenght of the spacer could be customized as your special demands.

Spacer for hydraulic modular trailer

3. Drop deck bed for Hydraulic modular trailer

The "Drop deck bed" could load Max. 200 tons cargo for Goldhofer THP/SL.

Drop deck bed for Hydraulic modular trailer

3. Bolster for Hydraulic modular trailer

"Bolster/ Turntable" tooling is for long and high strength cago. It can reduce the modular trailer axle amounts, and the steering angle is much more bigger!

bolster for hydraulic modular trailer


4. Windmill Tower Adapter

Supro Trailer produce "Windmill Tower Adapter", and also Supro trailer produce "Windmill Blade Adapter". "Supro Extendable trailer" is also for the windmill blade transport.

Please visit the products of "Supro Windmill Industry Trailer" to check our trailers.

windmill tower adapter for hydraulic modular trailer


 Nicolas modular trailer specification sheet

Supro Modular Trailer Combine Nicolas Modular Trailer
2990mm Width Modular Trailer
Description 2990mm Width Maximum load capacity
Height/Width (mm) Wheelbase (mm) Tread (mm) Tyre Size Axle Capacity Max. Payload (t) Min. Height (mm) Min. Travelling height(mm)
1050(+250/-300)/2900 1550 1820/735 215/75R17.5 22.5 20/60 800 900

3400mm Width Modular Trailer
Description 3400mm Width Maximum load capacity
Height/Width (mm) Wheelbase (mm) Tread (mm) Tyre Size Axle Capacity Max. Payload (t) Min. Height (mm) Min. Travelling height(mm)
1050(+250/-300)/2900 1550 1820/735 215/75R17.5 22.5 20/60 800 900












660mm height Nicolas modular trailer

Nicolas Hydraulic modular trailer- Min. 660mm height specification sheet
Description Axle No Gross WT. kg Tare WT.kg Rated Capacity kg. Tyre /pcs Min.Taming Radius/mm Out side size (mm)
Inside Out side Length Width Height
45t 2 55400 10400 45000 16 450 4070 3000 2990 910
65t 3 78500 13500 65000 24 1500 5800 4500 2990 910
90t 4 106600 16600 90000 32 2600 7600 7600 2990 910
110t 5 129700 19700 110000 40 1500 5800 5800 2990 910
135t 6 157800 22800 135000 48 2000 6700 6700 2990 910
155t 7 180800 25800 155000 56 2600 7600 7600 2990 910
180t 8 208900 28900 180000 64 3100 8500 8500 2990 910

Nicolas trailer model speed and capacity table:

Speed (km/h)

Loading (tons)

5

22

10

21

15

20

20

19

25

17

30

16

35

15

40

14

60

13

80

12

Draft of Nicolas model trailer/Supro Trailer

Nicolas modular trailer drawing

Nicolas Model Multi axle modular trailer Combination choice:

hydraulic modular trailer
